The IDE FUN MARINE 110, Honda GX200 Petrol driven portable breathing air compressor is a compact power house that is corrosion-resistant and built for the true off grid Adventurer.
Its powder-coated stainless steel frame, painted aluminium compressor block, stainless steel cooler and stainless steel screws guarantee absolute corrosion resistance. It is the ideal breathing air compressor for salty marine environments. The FUN MARINE delivers certified breathing air in accordance with DIN EN 12021:2014 – wherever you are, whenever it is needed. This makes it an ideal compressor for recreational divers, instructors, or professionals needing a mobile air supply, the Fun Marine 110 portable breathing air compressor makes self-sufficiency easy, just plug it in and fill your cylinders on your schedule. The Bavaria Fun Marine delivers freedom, efficiency, and quality in one compact package.
This IDE Bavaria Fun Marine 110 portable breathing air compressor is available with many different power sources so you can pick the one that suits you best.
- 230V 50Hz
- 115V 60Hz for USA power supply
- 400V 50Hz three phase
- petrol drive
The IDE breathing air IKB 110 compressor block
At he heart of this Compressor you will find the IKB 110 compressor block. This compressor block has been on the market for over a decade, proven and appreciated a thousand times over. It’s a highly efficient machine thanks to the innovation and development of IDE. Robustly built with long maintenance intervals, thanks to optimised valves and pistons in the 3-cylinder, 3-stage compressor block. This compressor block has 1st, 2nd, and 3rd stage safety valves, aluminum cylinders, some with gray cast iron liners, aluminum pistons with special piston rings for a long service life, free-floating pistons in the last stage. 2 condensate separators with vent valves, oil-slinger pin safety lubrication. there is a free-floating piston in the 3rd stage and special cylinder heads with reduced dead space. The special cylinder heads with reduced dead space and particularly effective cooling ensuring over 10% more power with the same drive power to many competitors. easy access to all components, oil dipstick for quick checks and many other clever details, make this one of the world‘s most popular compressor blocks.
IDE FT 100 Triple- Plus dryer system
The FT 100 Triple-Plus dryer system has an integrated oil and water separator in with the downstream pressure retention non-return valve and the original IDE FT 100 dryer cartridges. The breathing air is optimally treated in accordance with DIN EN 12021. A tested, sealed final pressure safety valve ensures maximum operational safety. At a housing temperature of 20 °C, the volume of air that can be treated is approx. 140 m³. With proper installation, maintenance and and a maximum CO₂ concentration in the intake air in accordance with DIN EN 12021-2014.
Honda GX200 Black edition
The compressor version with 4- stroke petrol engine offers mobile independence from the power grid – ideal for flexible off-road use.
- 4.3 kW, 6.0 HP
- low-maintenance V-belt drive
- Noise level of approx. 96 dB(A).
- Built in oil alert system
- Built in Circuit protection
IDE FT 100 dryer cartridges
During compression, a water-oil mixture is produced in the two separators, which is separated manually or automatically. However, a certain amount of residual moisture remains in the air. This flows through the IDE FT 100 Triple Plus dryer system, where a regularly re- placed dryer cartridge removes the residual moisture. The cartridges are manufactured to a high standard, filled with the best materials and carefully tested. They filter aerosol oil, oil vapours, moisture, carbon and other impurities from the air.
What’s Included in my delivery:
- Auto-stop included as standard when the final pressure is reached
- Inox stainless finish
- Air flow rate 110 L/min, 3-6.6 m³h, 2.11-3.88 cfm.
- Micronic intake filter
- Final pressure gauge
- 1 filling connection DIN 200 or 300 bar with venting on a 1.2 m hose.
- Triple+ FT 100 clean air dryer system for approximately 130 m³ of clean air according to DIN 12021:2014
- Compressor oil
- Tool set
- Operator’s manual
- Parts manual
- 1 year world wide warranty
Optional Add Ons:
- Airsave Basic filter saturation and service interval monitoring system
- Automatic condensate drains (self assembly or pre-assembled)
- Pressure change unit
- Pressure reducer with blow off
THE IDE BREATHING AIR PORTABLE COMPRESSORS HAVE 40% BETTER AIR PERFORMANCE, 20% LESS ENERGY CONSUMPTION, AND 10% MORE POWER THAN ANY OTHER BRAND! YOU JUST WON’T BUY BETTER!
Made in BAVARIA. Proven over 3000 times for 10 years.
Subject to technical changes. Illustrations may contain optional extras.
